It’s easy to underestimate the risks that can come with working with vibrating power tools on a daily basis. Occupational health adviser Bruce Ormiston looks at what OH professionals need to know.
According to the Health and Safety Executive (HSE), employees who use power tools on a regular basis are at risk of suffering permanent damage to their physical wellbeing. The HSE (2011) also said that an important health and safety issue facing many construction and other heavy-industry workers is the risk of vibration injury from handheld tools that leads to a condition called hand-arm vibration syndrome (HAVS). Chetter, Kent and Kester (1998) describe HAVS as “a complex disorder of the upper limbs found in people whose work involves the use of vibrating tools. The condition is characterised by the presence of vascular, neurological and musculoskeletal disturbances, but any of these three components may predominate”.
O’Hagan (2012) says that HAVS is estimated to cost UK companies millions of pounds per year in compensation, working days lost to injuries and fines. HAVS was only officially listed as a prescribed condition in the UK in 1985, but the HSE reported that it has become the biggest risk facing any worker who uses vibrating tools or equipment on a daily basis.
Over-exposure to vibration can lead to painful and disabling injuries affecting the blood vessels, nerves, joints and muscles in the hands and arms and, according to O’Hagan (2012), in extreme cases can even cause loss of fingers.
Defining the condition
Over-exposure to vibration can lead to painful and disabling injuries affecting the blood vessels, nerves, joints and muscles in the hands and arms and in extreme cases can even cause loss of fingers.”
In Hunter’s Diseases of Occupations, Pelmear (1999) defines the term HAVS as the collective name for a range of injuries caused by hand-transmitted vibration (HTV), including damage to the circulatory systems and sensory nerves in the fingers. It weakens the muscles in the hand and causes painful joints in the hands and arms. It is also known as vibration white finger (VWF) because the condition arises from regular, long-term use of tools that transmit vibration.
French and Italian miners were using pneumatic tools and developing hand symptoms that were described as “dead fingers” as far back as 1839. Pelmear (1998) calculates that an estimated 1.25 million workers were exposed to HTV in the US in 1974, and that this number had doubled by 1983.
In the UK, the number of workers exposed to HTV between 1984 and 1986 was estimated to be in excess of one million.
O’Hagan (2012) describes how the HSE introduced strict regulations that detailed the acceptable levels of vibration to which workers can be exposed.
The Control of Vibration at Work Regulations 2005 define how much vibration is acceptable in the form of an exposure action value – in other words, the amount of vibration exposure above which employers are required to take preventative action.
Several well-known and respected OH organisations in the UK – including the HSE, Constructing Better Health and the Faculty of Occupational Medicine (FOM) – have published literature about the dangers of HTV and the importance of employers maintaining their responsibility by ensuring employees are not injured because of excessive exposure to HTV.
O’Hagan (2012) reminds us that because the condition is listed as reportable, all incidences of HAVS mush be reported under the Reporting of Injuries, Diseases and Dangerous Occurrences Regulations 1995 (RIDDOR).
The Control of Vibration at Work Regulations 2005 introduced a statutory daily exposure action value and an exposure limit value for HTV. This information can be found in reg.4. Regulation 7 is very specific about the need for health surveillance for employees who are regularly exposed to HTV and how such surveillance should be carried out. The HSE (2005) also stipulated that health surveillance must take place when:
- employees are exposed to HTV above the current action value of 2.5 minutes over a standardised eight-hour day;
- if an employee is occasionally exposed to above the action value and a risk assessment identifies that this exposure may be hazardous to their health; and
- if an employee has a previous diagnosis of HAVS.
Regulation 7 (6) requires that employees cooperate with any health surveillance programmes and attend all health surveillance appointments that have been arranged by their employers.
Importance of health surveillance compliance
Pelmear (1998) and O’Hagan (2012) concur that HAVS is an extremely uncomfortable and often painful medical condition that can have a huge impact on the everyday lives of those affected by it.
Health surveillance is about having procedures in place in order to detect any work-related ill health or injury at an early stage and be able to act on these findings.
The aim is to safeguard the health of employees and to ensure the effectiveness of the company’s existing control measures.
The objective of health surveillance for HAVS is, therefore, to identify symptoms and/or prevent employees from developing symptoms that are associated with this disabling condition.
HAVS is an extremely uncomfortable and often painful medical condition that can have a huge impact on the everyday lives of those affected by it.”
Some employees may not even be aware that they have hand-related problems, and this can be the appropriate and relevant health surveillance that will help them recognise they may have the initial symptoms of HAVS.
The HSE (2005) requires employers to report any cases of HAVS arising from work activities associated with the exposure to HTV under RIDDOR. This comes into effect when a formal diagnosis by a HAVS-qualified doctor has been made, confirming that the employee has the condition and that it is likely to have an occupational origin. HAVS symptoms include:
- numbness and tingling in the fingers and a reduced sense of touch and temperature, caused by damage to nerves in the hands. This damage can make it difficult to feel and to work with small objects; and
- periodic attacks that affect blood circulation in the fingers, which then become white. This is sometimes known as VWF, dead finger or dead hand. The fingers usually feel numb, and as the blood circulation returns to normal either by itself or by re-warming the fingers typically become throbbing, red and painful.
Pelmear (1998) found that while unprotected exposure to excessive hand-held vibration is known to cause the condition, it does not cause the attacks. He pointed out that the main trigger for the symptoms was exposure to cold conditions – for example, being outdoors on a winter morning – and that in advanced cases the blood circulation may be permanently affected.
Under the Control of Vibration at Work Regulations 2005, health surveillance for HAVS uses a tiered approach:
- Tier 1 is a short questionnaire used as a first check for employees who are moving into roles – usually at pre-placement stage – where they may be exposed to HTV. The answers to the questions will indicate if a further detailed HAVS assessment is required.
- Tier 2 is also a short questionnaire that should be completed annually by employees who are exposed to HTV to check whether or not they need further assessment because of the development of new symptoms.
- Tier 3 includes a detailed HAVS questionnaire and a clinical examination, with assessment of any hand symptoms by a qualified individual such as an OH nurse. If any symptoms are found that are consistent with HAVS, the employee will then be referred on for a Tier 4 assessment. The Control of Vibrations at Work Regulations also stipulate that employees exposed to HTV at or above the action value must be assessed at the Tier 3 level at least every three years, and that employees who have active HAVS symptoms should be assessed annually at this level if they continue to be exposed to vibration at work.
- Tier 4 involves the formal diagnosis of HAVS and is carried out by a doctor qualified in OH. The doctor advises both the employer and employee about the worker’s continued fitness for work and what restrictions are required due to the diagnosis of HAVS.
- Tier 5 is optional and would involve referring the employee for certain specialist tests and assessments. The results are often used to assist the physician in making the correct diagnosis and recommending appropriate restrictions, which may include that the employee is unfit to work with hand-held vibrating tools because of the extent of existing hand symptoms.
Who can carry out HAVS health surveillance?
The Regulations also specify who can carry out what kind of health surveillance at the different tiers. Tier 1 and 2 surveillance can be carried out by non-clinically trained individuals, and it is often useful to appoint a “responsible person” to carry out this level of health surveillance. At a minimum, the “responsible person” should:
- have experience of the working environment they are monitoring and the ability to gain the confidence and cooperation of the employees involved;
- have received training for this type of health surveillance from a qualified OH professional, although they do not need to have a clinical qualification;
- fully understand the HAVS health surveillance procedure and the importance of confidentiality;
- be aware of what HAVS symptoms are, but not attempt to diagnose the condition; and
- not come to any medical conclusions or judgments in any reports regarding employees that have hand symptoms that may be consistent with HAVS.
Qualifications needed by OH professionals in HAVS
The Regulations also define appropriate OH qualifications for health surveillance of HAVS for both nurses and doctors.
Doctors should have a diploma and associateship or membership of FOM. Nurses should have a diploma, degree or a Masters in occupational health. Both doctors and nurses should hold a certification from a FOM-approved training course in HAVS or an equivalent level of competency.
The author of this article has reviewed several pieces of research that were carried out between 2000 and 2010 (Heaver et al, 2011; Mason, Poole and Saxton, 2001; Edwards and Holt, 2010), which concluded that accurate diagnosis and staging of HAVS is a very important element in health surveillance, thus reinforcing the requirement that only fully trained and competent OH clinicians should be conducting this type of diagnostic assessment.
Research into HAVS
Mason, Poole and Saxton (2001) set out to assess the diagnostic value of the cold provocation test. Their results were inconclusive because they found only limited evidence that the standardised test was of value when attempting to diagnose HAVS. They concluded that regular and stringent health surveillance would be the best way of maintaining a good history of symptoms and recording any potential for progression.
Heaver et al (2011) concluded that early recognition and prevention was the key element in managing vibration exposure in most workers exposed to HTV.
Early recognition and prevention was the key element in managing vibration exposure in most workers exposed to HTV.”
Edwards and Holt (2010) concluded that appropriate risk assessment of the exposure to vibration is necessary to avoid both injury to workers and medico-legal cases for compensation from employers. They also found that suitable health surveillance was of significant benefit in the early identification of symptoms, and recognised that incompetent OH clinicians may miss symptoms, which could lead to misdiagnosis and to employees suffering from life-long injuries.
The work of Pelmear and Leong (2010) is based on reviewing the current treatment options, prevention strategies and international standards for HAVS. They conclude that the levels of exposure to HTV should be adjusted to prevent the incidence of VWF from exceeding the regulation levels in Europe, Asia and the US, and endorse the importance of regular health surveillance being carried out by qualified OH clinicians.
Several authors – including O’Hagan (2012), White (2011) and the HSE (2012) – agree that the scale of the issue is vast, and have estimated that more than two million people in the UK alone are currently expected to be at risk of developing injuries caused by their daily exposure to vibrating tools and equipment.
It is very important for OH professionals to have a full knowledge of the symptoms of HAVS, how to carry out appropriate health surveillance and be able to extract the best and appropriate information from the workers, many of whom are poor historians of their own symptoms.
Anecdotal evidence also reveals that while the majority of construction workers are aware of HAVS and of how they may be affected by the condition, they regard this as “just part of the job” and do not fully understand the importance of regular monitoring and health surveillance.
Bruce Ormiston is a senior occupational health adviser at the Institute of Occupational Medicine
Chetter C, Kent PJ, Kester RC (1998). “The hand-arm vibration syndrome: A review”. Cardio Vascular Surgery; vol.6, pp.1-9.
Edwards DJ, Holt GD (2010). The cost-effective risk assessment of hand-arm vibration exposure.
Health and Safety Executive (1999). Understanding health surveillance at work: an introduction for employers.
Health and Safety Executive (2005). Hand-arm vibration syndrome – Control of Vibration at Work Regulations 2005.
Health and Safety Executive (2012). “Health and safety statistics: Key annual figures 2010/11″.
Heaver C et al (2011). Hand-arm vibration syndrome: a common occupational hazard in industrialised countries.
Mason HJ, Poole K, Saxton J (2001). A critique of a UK standardised test of finger rewarming after cold provocation in the diagnosis and staging of hand-arm vibration syndrome.
O’Hagan J (2012). “In safe hands: the importance of vibration monitoring”. Occupational Health; vol.64, issue 3, pp.10-11.
Pelmear PL (1998). Hand-Arm Vibration: A comprehensive Guide for Occupational Health Professionals (2nd edition). OEM Press; Massachusetts.
Pelmear PL (1999). In: Baxter P et al (eds). Hunter’s Disease of Occupations (9th edition). Arnold; Bath.
Pelmear PL, Leong D (2010). Review of occupational standards and guidelines for hand-arm (segmental) vibration syndrome (HAVS).
White P (2011). Construction Division. Plan of Work 2011/2012. HSE Books; London.
